Fire suppression & Detection

Fire suppression & Detection

The BRIGITDETEC difference BRIGITDETEC systems use a proprietary continuous linear sensor tube that reliably detects and actuates release of the extinguishing agent using pneumatic technology. It is more flexible, space efficient and cost effective versus alternative mechanical or electronic systems. Quick and Easy installation directly inside electrical cabinets. The flexible sensor tubing is easily installed inside the electrical cabinet directly above the wires and circuitry where a fire could start. When in service, the tubing is pressurised with dry nitrogen to 16 bar. The dynamics of pressurisation make the tubing more reactive to heat. Early fire detection If a flame-up occurs, the heat of the fire causes the pressurised sensor tube to burst at the hottest spot (approx. 110°C). Instant suppression The sudden tube de-pressurisation actuates the special pressure differential valve and instantly floods the entire cabinet area with CO2 extinguishing agent. The fire is quickly suppressed just moments after it began, minimising damage and downtime.

Product code: Built to order
